Sant D' raz ak fraisage machin zouti
Pwodwi sa a se yon gwo presizyon CNC machining ekipman ak yon konsepsyon bwat disk-kalite bwat. Li ka itilize pou yon varyete teknik pwosesis, ki gen ladan fraisage, perçage, engraving, raz, elatriye Anplis de sa, ekipman an ekipe ak yon sistèm automatisation efikas ak yon sistèm kontwòl egzak asire presizyon ak efikasite nan pwosesis la tout antye pwosesis. .
Ekipman sa a sèvi ak teknoloji avanse pwosesis ak materyèl, tankou gwo-fòs materyèl jete fè, segondè-presizyon pwosesis fanm k'ap pile, elatriye, fè li gen gwo rezistans chòk, rezistans mete ak estabilite. An menm tan an, ekipman an tou adopte teknoloji avanse CNC, ki fè li senp ak pratik yo opere, efikas ak ekonomize enèji, epi li ka satisfè divès kalite bezwen pwosesis segondè-presizyon.
Ekipman sa a lajman itilize nan machin presizyon, fabrikasyon otomobil, endistri ayewospasyal, ekipman medikal ak lòt domèn. Li gen pi wo efikasite pwosesis, pi wo presizyon pwosesis ak pi long lavi sèvis, pote plis benefis pratik nan kliyan yo.
Nan ti bout tan, ekipman sa a se yon ekipman pwosesis CNC ak fonksyon konplè, pèfòmans ki estab, operasyon fasil, efikasite segondè ak ekonomize enèji. Li se pi bon chwa ou a amelyore efikasite pwodiksyon ak asire bon jan kalite pwodwi.
| Espesifikasyon | inite | VMC650 | VMC850 | VMC855 | VMC1050 | VMC1160 | VMC1370 | VMC1580 |
| Gwosè tab la 工作台尺寸 |
manm | 900x400 | 1000X500 | 1000x550 | 1000x530 | 1200x600 | 1500x700 | 1700x800 |
| Chaj maksimòm tab la 工作台最大承重 |
kg | 350 | 500 | 500 | 600 | 1000 | 900 | 1500 |
| Vwayaj aks X/Y/Z X/Y/Z轴坐标行程 |
manm | 650x400x500 | 800x500x500 | 800x550x550 | 1000x500x600 | 1100x600x600 | 1300x700x700 | 1500x800x700 |
| Distans ant sant file koton ak kolòn 主轴中心线至立柱正面导轨距离 |
mm | 476 | 552 | 590 | 580 | 650 | 752 | 871 |
| Distans ant koton endface ak sifas worktable 主轴端面至工作台上平面距离 |
manm | 100-600 | 120-670 | 120-670 | 140-740 | 120-720 | 150-850 | 150-900 |
| X/Y/Z Max. vitès manje X/Y/Z最大进给速度 |
mm/min | 10000 | 10000 | 10000 | 10000 | 10000 | 8000 | 10000 |
| X/Y/Z Max. Traverse rapid X/Y/Z最大快移速度 |
m/min | 32/32/30 | 32/32/30 | 32/32/30 | 32/32/24 | 32/32/30 | 20/20/15 | 20/20/16 |
| vitès file koton 主轴转速 |
r% 2fmin | 8000 | 8000 | 8000 | 8000 | 8000 | 8000 | 8000 |
| cône file koton 主轴锥孔 |
kalite | BT40 | BT40 | BT40 | BT40 | BT40 | BT40 | BT50 |
| Pouvwa motè koton 主轴电机功率 |
kW | 5.5/7.5 | 7.5/11 | 7.5/11 | 7.5/11 | 11/15 | 11/15 | 15/18 |
| X/Y/Z aks servo motè pouvwa X/Y/Z轴伺服电机功率 |
kW | 2.6/2.6/2.8 | 3.9/3.9/3.6 | 3.9/3.9/3.6 | 3.9/3.9/3.6 | 4/4/5 | 4/4/5 | 4.5/4.5/4.5 |
| X/Y/Z koneksyon motè X/Y/Z电机连接方式 |
Dirèk 直联 |
Dirèk 直联 |
Dirèk 直联 |
Dirèk 直联 |
Dirèk 直接 |
Dirèk 直接 |
Dirèk 直接 |
|
| X/Y/Z Gid fason kalite X/Y/Z导轨类型 |
Liy ray 线轨 |
Liy ray 线轨 |
Liy ray 线轨 |
Liy ray 线轨 |
twazyèm liy 3线 |
De liy ak yon liy difisil 2线一硬 |
De liy ak yon liy difisil 2线一硬 |
|
| T plas 工作台T型槽 |
manm | 3-18x125 | 5-18x90 | 5-18x90 | 5-18x90 | 5-18x100 | 5-18x145 | 5-22x145 |
| Repete presizyon pwezante 重复定位精度 |
manm | ±0.004 | ±0.004 | ±0.004 | ±0.004 | ±0.005 | ±0.005 | ±0.005 |
| Zouti magazin 刀库形式 |
Kalite chapo / kalite disk 斗笠式/圆盘式 |
Kalite chapo / kalite disk 斗笠式/圆盘式 |
kalite disk 圆盘式 |
kalite disk 圆盘式 |
kalite disk 圆盘式 |
kalite disk 圆盘式 |
kalite disk 圆盘式 |
|
| Kapasite zouti 刀库容量 |
16T/16T | 24T | 24T | 24T | 24T | 24T | 24T | |
| Maksimòm pwa zouti 最大刀具重量 |
kg | 7 | 8 | 8 | 8 | 8 | 8 | 15 |
| Max. longè zouti 最大刀具长度 |
manm | 250/300 | 250/300 | 300 | 250/300 | 300 | 300 | 300 |
| Kapasite elektrik 电气总容量 |
kva | 10 | 15 | 15 | 15 | 18 | 22 | 30 |
| Dimansyon machin (LxWxH) 机床尺寸(长x宽x高) |
manm | 2300x2000x2300 | 2600x2380x2700 | 2600x2380x2700 | 3200x2420x2400 | 3100x2490x2380 | 3600x3000x2700 | 4260x3545x3200 |
| Net. pwa (apeprè) 机床重量(约) |
kg | 4500 | 5000 | 5000 | 6000 | 7000 | 11000 | 12000 |
